Meaning
Electromagnetic field sampling performed on a closed spherical surface enclosing the emitting source provides a complete characterisation of an antenna. In wireless testing, spherical near-field measurements allow engineers to capture the amplitude and phase of the emitted field at a close distance and mathematically project them to the far-field region. This technique is highly valued for testing compact devices and antennas with wide-angle emission patterns.
It allows the use of smaller chambers compared to traditional direct far-field ranges.
Mathematical Transformation
Fast Fourier transforms and spherical wave expansion algorithms translate the near-field data into the standard far-field patterns. This calculation relies on the orthogonality of spherical vector wave functions over the scanned surface. The resulting far-field pattern includes the full three dimensional polarimetric information of the antenna under test.
System Requirements
Dual polarised probes and high-precision multi-axis positioners are essential to collect the spatial samples over the sphere. The probe must be aligned with high accuracy to avoid polarization leakage and phase center offsets. In addition, the scanning system must maintain a constant radius during the rotation of the device.
Test Execution
Sampling grids are determined by the size of the antenna in terms of wavelengths to satisfy the spatial sampling requirements. This ensures that the scan captures the high-frequency angular details of the emission pattern.
