Meaning
Alignment of the optical axes of individual lens elements with the mechanical axis of the lens barrel ensures uniform image quality. Correct optical centration prevents the introduction of coma and astigmatism in the center of the field. Each element must sit precisely in its seat to maintain a common center.
Misalignment leads to a tilted focal plane. This condition is limited by the mechanical tolerances of the lens cells and spacers.
Axial Alignment
Precision machining of the housing provides the reference for the glass components. If the optical centration is poor, the lens will show more blur on one side of the image than the other. Adhesive bonding often secures the lenses after alignment.
This step is permanent.
Image Asymmetry
Variations in sharpness across the sensor indicate a centration problem. While a perfectly centered system is symmetric, any deviation causes the peak resolution to shift away from the center. Testing tools measure the modulation transfer function at multiple points to detect this shift.
Uniformity is the goal.
Assembly Tolerance
Manufacturing limits define the allowable error for each component. Active alignment during the assembly of a camera module can compensate for minor optical centration errors in the individual parts. The lens is moved relative to the sensor until the image is balanced.
Small adjustments in the six degrees of freedom allow the technician to find the optimal position for the entire stack. This process optimizes the yield.
